Product Specifications
| Part Number: | 33437 |
| UPC Number: | 765809334373 |
| Style: | Cartridge Fuel Metal Free Filter |
| Service: | Fuel |
| Type: | Full Flow |
| Media: | Cellulose |
| Height: | 9.6 (244)* |
| Outer Diameter Top: | 5.04 (128)* |
| Outer Diameter Bottom: | 4.67 (119)* |
| Inside Diameter Top: | 0.64 (16)* |
| Inside Diameter Bottom: | 0.75 (19)* |
| Nominal Micron Rating: | 30 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Packed (O-Ring) | 0.47 (12)* | 0.31 (8)* | 0.08 (2)* |
| Packed | 4.73 (120)* | 4.47 (114)* | 0.13 (3)* |
Principle Application:
| Principle Application: | Racor FH900, FH1000 Turbine Fuel Series for Over-the-Road Trucks (02 and up) - 30 Micron - 33437 is the OE style (taller, light media) - 33791 is the after-market version (slightly shorter, dark media) both work fine |
