Product Specifications
| Part Number: | 33996 |
| UPC Number: | 765809339965 |
| Style: | Spin-On Fuel Filter |
| Service: | Fuel |
| Type: | Full Flow |
| Media: | Cellulose |
| Height: | 3.212 (82)* |
| Outer Diameter Top: | 3.149 (80)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 16X1.5 MM |
| Max Flow Rate: | 1.500 |
| Nominal Micron Rating: | 4 |
| Flow Direction: | Outside-In |
| Capacity: | 13 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 2.815 (72)* | 2.461 (63)* | 0.2 (5)* |
Principle Application:
| Principle Application: | Applications with Deutz Diesel engines - (w/standpipe - if standpipe not required, use 33961) |
