Product Specifications
| Wix Number: | 51386 |
| UPC Number: | 765809513860 |
| Style: | Spin-On Lube Filter |
| Service: | Lube |
| Type: | Full Flow |
| Media: | Enhanced Cellulose |
| Height: | 5.17 (131)* |
| Outer Diameter Top: | 4.285 (109)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 20X1.5 MM |
| By-Pass Valve Setting-PSI: | 18-22 |
| Anti-Drain Back Valve: | Yes |
| Beta Ratio: | 2/20=22/44 |
| Burst Pressure-PSI: | 325 |
| Max Flow Rate: | 9-11 GPM |
| Nominal Micron Rating: | 32 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 3.967 (101)* | 3.587 (91)* | 0.340 (9)* |
Principle Application:
| Principle Application: | Caterpillar Equipment, Mitsubishi FE Series Trucks |
