Product Specifications
| Wix Number: | 51410 |
| UPC Number: | 765809514102 |
| Style: | Spin-On Hydraulic Filter |
| Service: | Hydraulic |
| Type: | Full Flow |
| Media: | Enhanced Cellulose |
| Height: | 3.79 (96)* |
| Outer Diameter Top: | 3.66 (93)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 3/4-16 |
| By-Pass Valve Setting-PSI: | None |
| Beta Ratio: | 2/20=6/20 |
| Burst Pressure-PSI: | 325 |
| Max Flow Rate: | 7-9 GPM |
| Nominal Micron Rating: | 21 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 2.729 (69)* | 2.415 (61)* | 0.2 (5)* |
Principle Application:
| Principle Application: | Ariens, Bolen, Case, IHC, John Deere, Kohler, Toro, Other |
