Product Specifications
| Wix Number: | 51614 |
| UPC Number: | 765809516144 |
| Style: | Spin-On Hydraulic Filter |
| Service: | Hydraulic |
| Type: | Full Flow |
| Media: | Wire Mesh |
| Height: | 5.745 (146)* |
| Outer Diameter Top: | 3.73 (95)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 1-12 |
| By-Pass Valve Setting-PSI: | None |
| Burst Pressure-PSI: | 400 |
| Nominal Micron Rating: | 141 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 2.865 (73)* | 2.500 (64)* | 0.125 (3)* |
Principle Application:
| Principle Application: | Zinga Hydraulic Systems - (Has wire mesh media - 141 micron) |
