Product Specifications
| Wix Number: | 51649 |
| UPC Number: | 765809516496 |
| Style: | Spin-On Lube Filter |
| Service: | Lube |
| Type: | Full Flow |
| Media: | Enhanced Cellulose |
| Height: | 8.058 (205)* |
| Outer Diameter Top: | 4.658 (118)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 1 1/2-12 |
| By-Pass Valve Setting-PSI: | None |
| Beta Ratio: | 2/20=10/20 |
| Burst Pressure-PSI: | 315 |
| Max Flow Rate: | 28-30 GPM |
| Nominal Micron Rating: | 15 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 4.320 (110)* | 3.820 (97)* | 0.365 (9)* |
Principle Application:
| Principle Application: | Cummins Engines, Hino Trucks, Hitachi, Other (if anti-drain back valve required, use 57239) |
