Product Specifications
| Wix Number: | 57249 |
| UPC Number: | 765809572492 |
| Style: | Spin-On Lube Filter |
| Service: | Lube |
| Type: | By-Pass |
| Media: | Cellulose |
| Height: | 7.634 (194)* |
| Outer Diameter Top: | 4.25 (108)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 20X1.5 MM |
| By-Pass Valve Setting-PSI: | None |
| Burst Pressure-PSI: | 200 |
| Max Flow Rate: | 8-10 GPM |
| Nominal Micron Rating: | 15 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 4.24 (108)* | 3.7 (94)* | 0.23 (6)* |
Principle Application:
| Principle Application: | Hitachi Excavators, Kobelco Excavators |
