Product Specifications
| Part Number: | WF10013 |
| UPC Number: | 765809223639 |
| Style: | Spin-On Fuel/Water Separator Filter |
| Service: | Fuel |
| Type: | |
| Media: | Enhanced Cellulose |
| Height: | 9.59 (244)* |
| Outer Diameter Top: | 4.23 (107)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 1-14 |
| Beta Ratio: | 99=9 |
| Max Flow Rate: | 0 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 3.9 (99)* | 3.56 (90)* | 0.22 (6)* |
Principle Application:
| Principle Application: | Racor Fuel Systems - replaces Racor # R120VC10 - this has a one-piece design w/ drain + sensor - eliminates the plastic bowl required for the Racor design - for Racor design (plastic bowl required), use 33782 - if you wish to add a plastic bowl to the WF10013, can add bowl part # WS10003 - remove the drain sensor from the bottom of the filter, install the bowl, then install the drain sensor to the bottom of the bowl. |
