Product Specifications
| Part Number: | WF10015 |
| UPC Number: | 765809223691 |
| Style: | Spin-On Fuel/Water Separator Filter |
| Service: | Fuel |
| Type: | |
| Media: | Enhanced Cellulose |
| Height: | 5.79 (147)* |
| Outer Diameter Top: | 4.23 (107)* |
| Outer Diameter Bottom: | Closed: |
| Thread Size: | 1-14 |
| Beta Ratio: | 75=25 |
( )* denotes metric
Gasket Diameters
| Number | O.D. | I.D. | Thk. |
|---|---|---|---|
| Attached | 3.51 (89)* | 3.17 (81)* | 0.25 (6)* |
Principle Application:
| Principle Application: | Racor Fuel Systems - One piece w/ drain (no sensor port) - can be used in place of 33630 to eliminate plastic bowl - 33992 is a one piece w/drain and sensor port - if you wish to add a plastic bowl to the WF10015, can add bowl part # WS10003 - remove the drain from the bottom of the filter, install the bowl, then install the drain to the bottom of the bowl. |
